Definitive Technology UIW RCS II In-wall Speakers multi-purpose speaker

This in-ceiling speaker is designed for custom-installed home theater systems or multi-room music setups, delivering precise, high-fidelity sound while remaining discreet. Its built-in back-box ensures well-balanced audio performance, protects against dust and debris, and optimizes bass response.

The speaker features dual 5-1/4″ polypropylene cone midrange/bass drivers with cast baskets for clear, accurate midrange and bass reproduction. Dual 6-1/2″ pressure-coupled passive radiators extend the low-frequency response, providing a rich, full-bodied sound. High frequencies are reproduced by a 1″ aluminum dome tweeter, delivering crisp, detailed audio.

An angled-baffle design directs sound toward the listening area, enhancing clarity and creating an immersive audio experience. The magnetic grille is paintable, allowing the speaker to blend seamlessly with any room décor. With a sensitivity of 92 dB and a nominal impedance of 8 ohms, this speaker is compatible with a wide range of amplifiers, delivering powerful, distortion-free performance across the 22 Hz–30 kHz frequency range.

Easy to install, this speaker requires a cutout of 14-3/8″W x 14-3/8″H and a mounting depth of 5-7/8″, making it ideal for both new construction and retrofit applications.

Features of In-Ceiling Speaker

• Single in-ceiling speaker for home theater or music systems

• Dual 5-1/4″ polypropylene cone midrange/bass drivers with cast baskets

• Dual 6-1/2″ pressure-coupled passive radiators for extended bass response

• 1″ aluminum dome tweeter for clear, detailed highs

• Built-in back-box for balanced sound and dust protection

• Angled-baffle design for precise sound direction

• Paintable magnetic grille for discreet aesthetics

• Indoor moisture-resistant design

• Easy installation with specified cutout and mounting depth

Specifications of In-Ceiling Speaker
