JBL P3607MX Array Frame for SRX906LA, support for up to (16) cabinets

JBL SRX906LA AF Array Frame

The JBL SRX906LA AF Array Frame is a compact and lightweight rigging solution designed for suspending SRX906LA and SRX915SF line array systems. Engineered for professional touring and installation environments, this array frame supports both single-point and front-back suspension methods, offering flexible deployment options for diverse venue requirements.

The frame features a two-piece collapsible design consisting of one extension bar and one spreader bar. This modular structure allows streamlined transport while maintaining structural integrity during operation. The extension bar can be configured to extend toward the front or rear of the frame, enabling precise uptilt or downtilt aiming adjustments to optimize audience coverage.

For single-point suspension applications, the SRX906LA AF can be used with a compatible rotating clamp, allowing smaller arrays to be suspended from standard trusses or pipes. Three selectable connection points enable accurate shackle positioning and precise pick-point resolution, ensuring controlled array balance and alignment.

Constructed from high-grade steel with an anti-corrosion coating and finished in durable black powder coat, the frame is designed for long-term reliability in demanding environments. The system supports compatible 1/2-inch shackles and accommodates third-party laser inclinometers such as TEQ-SAS and RECLINE for precise angle measurement. With defined mechanical load limits for both safe and maximum configurations, the JBL SRX906LA AF Array Frame delivers dependable and scalable suspension performance.

Features of SRX906LA AF

• Lightweight and compact array frame

• Compatible with SRX906LA and SRX915SF

• Supports single-point suspension

• Supports front-back suspension methods

• Two-piece collapsible design

• Adjustable extension bar for tilt control

• Three precision pick-point positions

• Compatible with 1/2-inch shackles

• Supports TEQ-SAS and RECLINE laser inclinometers

• High-grade steel construction

• Anti-corrosion protective coating

• Durable black powder coat finish

Specifications of SRX906LA AF
