Monitor Audio C2M-T2X In-Ceiling Speaker

Monitor Audio Creator Series Tier 2 in-ceiling loudspeaker

The Monitor Audio Creator Series Tier 2 in-ceiling loudspeaker is designed to deliver versatile high-fidelity audio performance for both music listening and immersive surround sound applications. Engineered as a large-format architectural speaker, it combines advanced acoustic technologies with flexible operating modes to provide expansive sound coverage and dynamic audio reproduction in premium residential and commercial installations.

This two-way loudspeaker features a 9-inch RST II dual-coil bass driver combined with dual 1.25-inch C-CAM tweeters integrated with UD Waveguide technology. The advanced driver configuration delivers powerful bass response, clear midrange detail, and precise high-frequency reproduction while maintaining wide and controlled sound dispersion. Its large driver design enhances low-frequency extension and overall output capability, making it suitable for demanding music and home cinema environments.

The loudspeaker supports three switchable operating modes for enhanced installation flexibility. Cinema Mono FX mode operates in a di-pole configuration with out-of-phase tweeters to create spacious surround sound effects for movies. Mono Wide Dispersion mode uses bi-pole operation with in-phase tweeters for broader room coverage, while Single Speaker Stereo mode allows two amplifier channels to connect to a single speaker for compact stereo installations.

Installation is simplified through the Quik-Link speaker cable connector, enabling fast and efficient wiring connections. The Tri-Grip II mounting system provides secure and reliable installation with strong ceiling fitment. With a 248 mm cut-out diameter and low-profile architectural design, the Creator Series Tier 2 loudspeaker integrates discreetly into ceilings while delivering high-performance audio reproduction with exceptional versatility for distributed music systems and surround sound applications.

Features of Creator Series Tier 2

• Large-format two-way in-ceiling loudspeaker
• Switchable three-mode speaker operation
• Single speaker stereo functionality
• Di-pole surround sound configuration
• Bi-pole wide dispersion configuration
• 9-inch RST II dual-coil bass driver
• Dual 1.25-inch C-CAM tweeters
• UD Waveguide tweeter technology
• Wide sound dispersion characteristics
• High-fidelity architectural audio performance
• Powerful bass and dynamic output
• Detailed and natural high-frequency response
• 30 Hz – 30 kHz frequency range
• 88 dB installed sensitivity
• 117 dB maximum peak SPL
• Quik-Link cable connector system
• Fast and simplified installation
• Tri-Grip II secure mounting system
• Compatible with CL-B bracket
• Optional square grille compatibility

Specifications of Creator Series Tier 2
