RCF MXR 4500/2 500W 2-Zone Voice Alarm Master Amplifier
RCF MXR 4500/2 combines 500 W total amplification and 2-zone control with digital processing, monitored emergency messages and integrated audio playback, providing a dedicated master unit for compatible professional voice alarm installations.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 20,959.05 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
RCF MXR 4500/2 500W 2-Zone Voice Alarm Master
The RCF MXR 4500/2 is an amplified master unit for the DXT 4000 voice alarm system, providing 500 W of total power and 2 independently controlled zones. It is designed for small and medium installations that need coordinated emergency announcements and background audio within a defined voice alarm architecture.
The integrated Class D amplification platform works with onboard digital signal processing to optimize environmental equalization and speech intelligibility. A spare-amplifier facility supports the planned system configuration. Emergency messages are held on a monitored SD card, while the front-panel audio source provides additional programme playback for everyday operation.
The unit is certified to EN 54-16, and its internal power supply is certified to EN 54-4. The complete installation combines the master unit with suitable loudspeaker lines, emergency controls and the required backup-power arrangement. Configuration and connection methods should follow the instructions for the exact master-unit version and its intended system.
Rack mounting uses a 19-inch, 4U enclosure. An IE 3008 interlink board is included, allowing up to eight units to operate in a master-slave configuration. This expands the system architecture while retaining a dedicated control relationship between the connected units and the supported audio and command paths.
Compatible microphone consoles include BM 3804, BM 3804FM and ME 3801, with BE 3806 extensions available for zone controls. The unit measures 178 mm high, 482 mm wide and 426 mm deep. Its black – ral 9005 enclosure provides the physical format for the selected 2-zone system configuration. The selected assembly should account for the dimensions of the accessory and the position of the supported equipment. Use the documented attachment sequence when establishing the final relationship between the connected components.
Features of MXR 4500/2
- 500 W total power
- Up to 2 zones controlled
- On-board DSP platform
- Certified EN 54-16 and EN 54-4
- Emergency messages on monitored SD card
- Spare power amplifier facility
- Integrated audio source on front panel
- Rack mount installation (4U)
- Up to 8 units connectable in a master-slave configuration
Specifications of MXR 4500/2
| Product Type | Amplified voice alarm master unit |
| Brand | RCF |
| Model | MXR 4500/2 |
| Manufacturer Part Number | 12100067 |
| Number of zones managed | 2 |
| Built-in power amplifier | Yes |
| Spare amplifier automatic change-over | Yes |
| Max number of consoles | 4 |
| Number of console buses | 1 |
| Number of simultaneous emergency audio channels | 1 |
| Max number of units connectable | 8 |
| Communication bus | Serial |
| Connection Cables | FTP CAT 5 |
| Integrated pre-recorded emergency messages | Yes |
| Amplifier Class | D+ |
| Number of channels | 2 |
| Output power @ 100 V (W) | 500 W RMS |
| A/B speakers line | Yes |
| Frequency Response (-3dB) | 80 Hz – 16 kHz |
| Signal/noise rate (”A” weighted) | >98 dB |
| Distortion (THD+N) @ 1 kHz nominal power | <0.3 % |
| Total number of inputs | 3 |
| Balanced | 3 |
| Mono | 3 |
| Line inputs | 2 |
| Line connectors | Euroblock, JACK |
| VOX | Yes |
| Paging inputs | 1 |
| Paging connectors | Euroblock |
| Paging command | Serial |
| Paging emergency | Yes |
| General Purpose Inputs (GPI) | 6 |
| Monitored GPI | 6 |
| Photo-coupled GPI | 6 |
| Signal output number | 1 |
| Signal output connectors | JACK |
| Power output lines | 2 |
| Power output connectors | Euroblock |
| General Purpose Outputs (GPO) | 6 |
| DSP | Yes |
| Tone controls | Yes |
| High-pass filter | 20 Hz – 500 Hz |
| Configuration | DIP switch, Front panel |
| Chime tone | Yes |
| Cooling | Convection |
| Short circuit | Yes |
| Thermal | Yes |
| DC | Yes |
| Fuses | Yes |
| VHF (Very High Frequencies) | Yes |
| USB pen drives | Yes |
| SD card | Yes |
| Voltage selection | Internal |
| DC power | Yes |
| DC power value | 48 V |
| Power consumption (MAX) | 700 W |
| EN54-16 certified | Yes |
| EN54-4 certified | Yes |
| CPR number | 0068-CPR-230/2025 |
| Cabinet/Case Material | Metal |
| Color | Black – RAL 9005 |
| Rack mounting | 19″, 4U |
| Height | 178 mm / 7.01 inches |
| Width | 482 mm / 18.98 inches |
| Depth | 426 mm / 16.77 inches |
| Weight | 11.3 kg / 24.91 lbs |
