TAGA TCA-240V Mixing Amplifier 6-Zone 240W Paging Mono Black

The TAGA Harmony TCA-240V Mixing Amplifier in Black is a professional-grade 6-zone mono amplifier designed for paging and background music systems in commercial and residential installations. Delivering a powerful 240W RMS output via a high-efficiency toroidal transformer, it supports both high-voltage (100V/70V) and low-impedance speaker configurations (4/8 Ohm – single zone only). Each zone features independent volume control, allowing tailored sound levels across multiple areas. The amplifier includes three analog LINE inputs and two microphone inputs with mixing capability, plus one priority mic input for emergency or announcement override. A built-in chime function alerts listeners before voice broadcasts. USB playback supports MP3, WAV, WMA, and APE formats, while treble/bass tone controls fine-tune system output. With mono RCA output for linking external amplifiers or subwoofers, signal/overload indicators, and active cooling fan, the TCA-240V is ideal for paging, music distribution, and voice broadcasting. Finished in matte black rackmount chassis with screw-in terminals and IEC power inlet.

APPLICATIONS

• 6-zone mono amplifier for paging and background music systems
• Perfect for restaurants, cafes, retail stores, offices, gyms, and conference halls
• Voice broadcast system with microphone priority and chime alert
• USB playback from flash drives with support for MP3, WAV, WMA, APE formats
• Three analog LINE inputs for CD players, tuners, or media streamers
• Two microphone inputs with mixing for announcements or karaoke
• Mono RCA output for connecting external amplifiers or powered subwoofers
• Compatible with 100V/70V speaker lines and 4/8 Ohm low-impedance setups
• Rackmount chassis for AV cabinets and structured wiring panels
• Ideal for installers, integrators, and multi-room commercial audio systems

FEATURES

• 240W RMS mono output via high-efficiency toroidal transformer
• 6 independent zones with separate volume control
• Supports 100V / 70V and 4/8 Ohm speaker configurations
• 3 × LINE inputs (RCA stereo mixed to mono)
• 2 × MIC inputs with mixing + 1 × MIC priority input
• Chime function for voice broadcast notification
• USB input supports MP3, WAV, WMA, APE playback
• Mono RCA output for external amp or subwoofer
• Treble / Bass tone control (global)
• Signal and overload LED indicators
• Cooling fan for long-duration operation
• Screw-in speaker terminals (up to 10AWG)
• Removable IEC power cable for upgrade flexibility
• Black rackmount metal chassis with front power switch

SPECIFICATIONS
