Crown Audio DCi 8|300DA 8-Channel Power Amplifier

Crown DCi 8|300DA

The Crown DCi 8|300DA DriveCore Install DA Series amplifier is a high-channel-density professional installation amplifier designed for large-scale distributed audio systems requiring Dante or AES67 networked audio integration. Built on Crown’s advanced DriveCore technology, it delivers efficient power amplification with low heat generation and high reliability in a compact 2RU chassis. With eight independent channels delivering 300W per channel at 4 ohms, it is ideal for complex multi-zone installations in commercial, institutional, and life-safety environments.

The amplifier supports redundant Dante and AES67 network audio via primary and secondary ports, ensuring uninterrupted and secure digital audio transmission. It operates at both 48 kHz and 96 kHz sampling rates and allows analog inputs to be transmitted over the network with pre- and post-processing options. Its integrated DSP engine provides comprehensive audio control, including input routing, EQ, crossover, delay, output processing, and LevelMAX limiting, enabling precise tuning and loudspeaker protection across multiple zones.

Designed for mission-critical applications, the DCi 8|300DA is EN 54-16 compliant, making it suitable for voice alarm and life-safety systems in accordance with European safety standards. Advanced monitoring features such as continuous load monitoring, sweep load analysis, and pilot tone detection ensure system integrity and fault detection. The amplifier also supports high, medium, and low priority inputs with configurable delay and processing options for intelligent audio distribution management.

Remote configuration and monitoring are handled via HiQnet Audio Architect software over standard TCP/IP networks, enabling centralized system control. Additional features include programmable GPIO ports for external control integration, auxiliary ports for status and control functions, removable air filters for maintenance efficiency, and front-panel LED indicators for real-time system feedback. With its combination of high channel count, networked audio capability, DSP control, and life-safety certification, the Crown DCi 8|300DA is engineered for demanding modern audio installations.

Features of DCi 8|300DA

• Eight-channel 300W per channel high-density design
• Dante™ and AES67 network audio support
• Redundant primary and secondary network ports
• Advanced DriveCore amplification technology
• Integrated DSP with full system processing tools
• Input routing, EQ, crossover, and delay control
• Output EQ and LevelMAX limiting protection
• Matrix routing and flexible signal distribution
• HiQnet Audio Architect remote control support
• EN 54-16 life-safety system compliance
• Continuous and sweep load monitoring system
• Pilot tone verification for system fault detection
• GPIO programmable control and integration ports
• Front-to-back efficient cooling system design
• AES67 compatibility for networked audio systems
• Multi-priority input signal management

Specifications of DCi 8|300DA
