Crown NCDI2X12BL-U-EU CDi 2|1200BL Analog + BLU link input, 2 channel Amplifier
The Crown CDi DriveCore 2|1200BL amplifier delivers powerful two-channel performance, integrated DSP processing, BLU link digital audio networking, and advanced DriveCore efficiency for professional installed sound applications.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 15,986.31 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
Crown CDi DriveCore 2|1200BL Power Amplifier
The Crown CDi DriveCore 2|1200BL is a professional 2-channel installation amplifier engineered for large-scale commercial and installed audio environments including cinemas, hotels, houses of worship, cruise ships, conference facilities, and entertainment venues. Built with advanced DriveCore amplifier technology derived from Crown’s flagship installation amplifier platforms, the amplifier combines high output power, flexible DSP processing, digital audio networking, and streamlined operation in a compact rackmount design.
Designed for modern installed sound systems, the CDi DriveCore 2|1200BL supports both low-impedance loudspeaker configurations and high-voltage 70V and 100V distributed audio systems without requiring external transformers. Delivering up to 1200 watts per channel, the amplifier provides reliable performance for demanding multi-zone and large-area installations. Integrated DSP processing enables advanced loudspeaker optimization, crossover adjustment, equalization, delay configuration, and system management directly within the amplifier.
A major advantage of the 2|1200BL model is integrated BLU link support, allowing audio channels to be transmitted and received across HARMAN’s digital audio bus network. This capability simplifies system integration and enables efficient audio distribution across complex installed sound infrastructures. Network control and monitoring functions further enhance centralized management and remote system configuration capabilities.
The amplifier also includes factory-loaded JBL loudspeaker tunings to accelerate installation setup and optimize speaker performance. High damping factor performance, low total harmonic distortion, and wide frequency response ensure accurate and detailed audio reproduction. Supporting bridge-mono operation for increased output power, the Crown CDi DriveCore 2|1200BL delivers flexible installation performance, advanced connectivity, and professional-grade reliability for commercial audio applications.
Features of CDi DriveCore 2|1200BL
- Professional 2-channel installation amplifier
- Advanced DriveCore amplifier technology
- Integrated BLU link digital audio networking
- High-level onboard DSP processing
- Network control and monitoring support
- Front-panel system interface
- Supports 70V speaker systems
- Supports 100V speaker systems
- Transformer-less distributed audio operation
- Factory-loaded JBL speaker tunings
- Bridge-mono operating capability
- High damping factor architecture
- Low distortion audio performance
- Compatible with low-impedance speakers
- Compact rackmount installation design
- Universal AC power compatibility
Specifications of CDi DriveCore 2|1200BL
| Product Type | Installation power amplifier |
| Amplifier Channels | 2 |
| DriveCore Technology | Yes |
| BLU Link Support | Yes |
| DSP Processing | Integrated |
| Network Control | Supported |
| Rated Power Output @ 2 Ohms | 850W per channel |
| Rated Power Output @ 4 Ohms | 1200W per channel |
| Rated Power Output @ 8 Ohms | 1200W per channel |
| Rated Power Output @ 16 Ohms | 600W per channel |
| Rated Power Output @ 70Vrms | 1200W per channel |
| Rated Power Output @ 100Vrms | 1200W per channel |
| Bridge Mono Output @ 4 Ohms | 1200W |
| Bridge Mono Output @ 8 Ohms | 2400W |
| Bridge Mono Output @ 16 Ohms | 2400W |
| Bridge Mono Output @ 140Vrms | 2400W |
| Bridge Mono Output @ 200Vrms | 2400W |
| Input Sensitivity | 0.7V RMS |
| Frequency Response | 20 Hz – 20 kHz ±0.25 dB |
| Total Harmonic Distortion | 0.35% |
| Damping Factor | >1000 |
| Crosstalk | >80 dB |
| Signal-to-Noise Ratio | >104 dB |
| Balanced Input Impedance | 20 kΩ |
| Unbalanced Input Impedance | 10 kΩ |
| JBL Speaker Tunings | Included |
| Distributed Audio Support | 70V / 100V |
| Front Panel Interface | Yes |
| Power Supply | 100 – 240V AC |
| Power Connector | 15A IEC |
| Rackmount Size | 2RU |
| Dimensions (W × H × D) | 19 × 3.5 × 14.71 in |
| Weight | 17.2 lb / 7.8 kg |
