Genelec S360AP-R Rackmount Black SAM/DSP Studio Monitor
Genelec S360AP-R Rackmount Black SAM/DSP Studio Monitor provides professional-grade sound accuracy in a space-saving rackmount design. Perfect for broadcast and control rooms, it integrates SAM technology for precise calibration and consistent output.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 23,175.56 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
The Genelec S360AP-R Rackmount Black SAM/DSP Studio Monitor brings the power, precision, and Smart Active Monitoring (SAM™) DSP technology of the S360AP into a convenient rackmount form. Designed for professional control rooms, broadcast vans, post-production facilities, and installations where space is limited, this monitor ensures accurate and consistent performance at high SPL levels. The 10″ woofer and 1.7″ titanium compression driver deliver detailed, controlled sound across the frequency spectrum, while GLM™ software enables room calibration, system integration, and network control.
APPLICATIONS –
- Rackmount Studio Installations: Perfect for broadcast, post-production, and professional audio racks requiring high-output monitoring in limited space.
- Professional Recording Studios: Delivers reference-grade sound for mixing, mastering, and production workflows.
- Post-Production Suites: Provides consistent monitoring for film, TV, and game audio environments.
- Broadcast & OB Vans: Suitable for mobile production setups, delivering reliable performance in acoustically variable conditions.
- Immersive Audio & Multi-Channel Systems: Integrates with GLM™ for calibration in Dolby Atmos®, Auro-3D®, and other immersive audio setups.
- Educational & Research Facilities: Ideal for audio training programs, laboratories, and research requiring repeatable, accurate monitoring.
FEATURES –
- Rackmount version of the Genelec S360AP with SAM™ DSP
- High-SPL 2-way active studio monitor with 500 W LF + 150 W HF Class-D amplification
- 10″ woofer and 1.7″ titanium dome compression driver for precise audio reproduction
- Frequency range: 36 Hz – 22 kHz (-6 dB)
- Directivity Control Waveguide (DCW™) for wide sweet spot and accurate imaging
- Compatible with Genelec Loudspeaker Manager (GLM™) for automatic room calibration
- Intelligent Signal Sensing (ISS™) power-saving standby mode
- Die-cast aluminum enclosure for low resonance and high rigidity
- Flexible connectivity: XLR analog and AES/EBU digital inputs and thru
- Rackmount design with front-panel accessibility and ventilation for secure installation
- High-fidelity performance suitable for broadcast, post-production, and professional studio use
SPECIFICATIONS –
| Category | Specification |
|---|---|
| Monitor Type & Configuration | Rackmount Active 2-Way SAM™ Studio Monitor |
| Total Power Output | 650 W (500 W LF + 150 W HF, Class D) |
| Woofer | 1x 10″ / 250 mm Cone |
| Tweeter | 1x 1.7″ / 44 mm Titanium Dome Compression Driver |
| Frequency Range | 36 Hz – 22 kHz (-6 dB) |
| Frequency Response | 39 Hz – 21 kHz (±2.5 dB) |
| Maximum SPL | 118 dB (Short Term) |
| Crossover Frequency | 1.8 kHz |
| THD (Total Harmonic Distortion) | <0.05% |
| Analog Inputs | 1x XLR Balanced Input |
| Digital Inputs | 1x XLR AES/EBU Input, 1x XLR AES/EBU Thru |
| Network I/O | 2x RJ45 for GLM™ Control Network |
| Enclosure Type | Bass-Reflex Ported Aluminum Enclosure |
| Material | Die-Cast Aluminum |
| Mounting Options | Rackmount Horizontal |
| AC Input Power | 100–240 VAC, 50/60 Hz |
| Power Consumption | 1 W (Standby), 10 W (Idle), 650 W (Max) |
| Dimensions (H x W x D) | 5U Rack x 565 x 347 mm / 22.2″ x 13.7″ |
| Weight | 30.5 kg / 67.2 lb |
| Color | Black |
| Included Accessories | Power Cable, GLM Network Cable, Rack Mount Hardware, User Manual |
