Genelec S360AW-R Rackmount White SAM/DSP Studio Monitor
Genelec S360AW-R Rackmount White SAM/DSP Studio Monitor merges sophisticated design with professional monitoring precision. With Smart Active Monitoring, it delivers consistent frequency response and accuracy for critical studio applications.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 23,175.56 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
The Genelec S360AW-R Rackmount White SAM/DSP Studio Monitor combines the accuracy and power of the S360AW with a convenient rackmount form factor. Designed for professional studios, broadcast vans, and post-production environments with space constraints, it delivers precise, high-SPL performance across the frequency spectrum. Equipped with a 10″ woofer and 1.7″ titanium dome compression driver, and integrated with Smart Active Monitoring (SAM™) DSP and Genelec Loudspeaker Manager (GLM™) software, the S360AW-R ensures optimized room calibration and seamless integration into multi-channel monitoring systems.
APPLICATIONS –
- Rackmount Studio Installations: Perfect for broadcast, post-production, and professional audio racks requiring high-output monitoring in limited space.
- Professional Recording Studios: Delivers reference-grade sound for mixing, mastering, and production workflows.
- Post-Production Suites: Provides accurate monitoring for film, TV, and game audio environments.
- Broadcast & OB Vans: Ideal for mobile production setups with reliable performance in acoustically variable conditions.
- Immersive Audio & Multi-Channel Systems: Integrates with GLM™ for calibration in Dolby Atmos®, Auro-3D®, and other immersive audio setups.
- Educational & Research Facilities: Suitable for audio training programs, laboratories, and research requiring repeatable, accurate monitoring.
FEATURES –
- Rackmount version of the Genelec S360AW with SAM™ DSP
- High-SPL 2-way active studio monitor with 500 W LF + 150 W HF Class-D amplification
- 10″ woofer and 1.7″ titanium dome compression driver for precise audio reproduction
- Frequency range: 36 Hz – 22 kHz (-6 dB)
- Directivity Control Waveguide (DCW™) for wide sweet spot and accurate imaging
- Compatible with Genelec Loudspeaker Manager (GLM™) for automatic room calibration
- Intelligent Signal Sensing (ISS™) power-saving standby mode
- Die-cast aluminum enclosure for low resonance and high rigidity
- Flexible connectivity: XLR analog and AES/EBU digital inputs and thru
- Rackmount design with front-panel accessibility and ventilation for secure installation
- Elegant white finish for aesthetic integration into studio environments
SPECIFICATIONS –
| Category | Specification |
|---|---|
| Monitor Type & Configuration | Rackmount Active 2-Way SAM™ Studio Monitor |
| Total Power Output | 650 W (500 W LF + 150 W HF, Class D) |
| Woofer | 1x 10″ / 250 mm Cone |
| Tweeter | 1x 1.7″ / 44 mm Titanium Dome Compression Driver |
| Frequency Range | 36 Hz – 22 kHz (-6 dB) |
| Frequency Response | 39 Hz – 21 kHz (±2.5 dB) |
| Maximum SPL | 118 dB (Short Term) |
| Crossover Frequency | 1.8 kHz |
| THD (Total Harmonic Distortion) | <0.05% |
| Analog Inputs | 1x XLR Balanced Input |
| Digital Inputs | 1x XLR AES/EBU Input, 1x XLR AES/EBU Thru |
| Network I/O | 2x RJ45 for GLM™ Control Network |
| Enclosure Type | Bass-Reflex Ported Aluminum Enclosure |
| Material | Die-Cast Aluminum |
| Mounting Options | Rackmount Horizontal |
| AC Input Power | 100–240 VAC, 50/60 Hz |
| Power Consumption | 1 W (Standby), 10 W (Idle), 650 W (Max) |
| Dimensions (H x W x D) | 5U Rack x 565 x 347 mm / 22.2″ x 13.7″ |
| Weight | 30.5 kg / 67.2 lb |
| Color | White |
| Included Accessories | Power Cable, GLM Network Cable, Rack Mount Hardware, User Manual |
