JBL Control 47HC High Ceiling Loudspeaker

JBL Control 47HC High Ceiling Loudspeaker

The JBL Control 47HC High Ceiling Loudspeaker is specifically engineered for high-ceiling and highly reverberant environments where controlled sound dispersion and speech intelligibility are critical. Featuring a narrow 75° conical coverage pattern, this model is designed to focus sound energy directly toward listening areas while minimizing reflections from walls, ceilings, and other architectural surfaces. This controlled dispersion significantly reduces time-arrival anomalies from adjacent loudspeakers and improves clarity in large, acoustically challenging spaces.

Built on the same sonic platform as the Control 47C/T series, the JBL Control 47HC High Ceiling Loudspeaker delivers consistent tonal balance and professional-grade audio quality while optimizing coverage for vertical distance and focused projection. This makes it ideally suited for high-traffic environments such as transit terminals, convention centers, airports, atriums, transportation hubs, and large public facilities where intelligible speech and controlled sound delivery are essential.

The system integrates JBL’s proprietary Conical RBI® (Radiation Boundary Integrator®) technology, ensuring precise pattern control and uniform frequency response across the listening area. The loudspeaker supports both low-impedance 8-ohm operation and 70V/100V distributed systems, providing flexible system integration for commercial audio installations. Equipped with a 165 mm (6.5 in) low-frequency driver and a 25 mm (1 in) high-frequency driver, the Control 47HC delivers balanced full-range performance in a compact ceiling format. With a formed-steel backcan, blind-mount installation design, fire-rated construction, and plenum compliance, the JBL Control 47HC High Ceiling Loudspeaker offers a reliable, scalable, and acoustically controlled solution for demanding professional environments.

Features of Control 47HC Ceiling

• Narrow 75° focused coverage pattern

• Optimized for high ceilings and reverberant spaces

• Improved speech intelligibility

• Controlled sound dispersion

• Conical RBI® pattern control technology

• Reduced acoustic reflections

• Low-impedance and 70V/100V operation

• Professional-grade coaxial driver system

• Elegant architectural design

• Blind-mount ceiling installation system

• Fire-rated and plenum-rated construction

• Consistent sonic character with Control 47 series

Specifications of Control 47HC Ceiling
