Description
JBL NVMA2120-34-EU Mixer-Amplifier
The JBL NVMA2120-34-EU Mixer-Amplifier is a versatile and cost-effective solution for commercial audio applications. Providing 120W per channel, it supports low-impedance speaker loads (4Ω/8Ω) as well as high-impedance distributed audio systems (70V/100V), making it ideal for offices, retail spaces, educational facilities, and other professional environments. Its fanless, 1U design allows quiet operation and easy integration into standard audio racks.
This model features eight inputs and two outputs, with independent bass and treble controls for precise tonal adjustment on each output channel. The NVMA2120-34-EU includes paging chime functionality, priority muting, and compatibility with JBL CSR-V in-wall volume controllers for convenient remote operation. Connectivity includes balanced mic/line inputs and unbalanced RCA inputs, supporting a wide variety of audio sources.
Engineered for reliable commercial performance, the NVMA2120-34-EU delivers low distortion (<0.5% THD), wide frequency response (20 Hz–20 kHz for low-impedance output, 80 Hz–15 kHz for high-impedance output), and high signal-to-noise ratio (>76 dB). It operates efficiently across international AC voltages (100–240V, 50/60 Hz) and is built to withstand standard commercial temperature and humidity conditions. The JBL NVMA2120-34-EU Mixer-Amplifier combines professional sound quality, operational flexibility, and durable construction, making it a dependable choice for modern commercial sound installations.
Features of NVMA2120-34-EU
8 inputs and 2 outputs with 120W power
Supports low-impedance (4Ω/8Ω) and high-impedance (70V/100V) outputs
Independent bass and treble adjustment for each output channel
Paging chime and priority muting
Compatible with JBL CSR-V wall controllers
Balanced mic/line inputs and unbalanced RCA inputs
Rack mounting hardware included
Wide frequency response and low distortion
High signal-to-noise ratio
Supports 100–240V AC operation
Fanless, compact 1U rack design
Durable commercial-grade construction
Specifications of NVMA2120-34-EU
| Max Output Power | 120 W @ 4/8Ω (1 kHz, ≤0.5% THD) |
| Insertion Loss (70V/100V) | 1 dB max |
| Number of Inputs | 8 |
| Number of Outputs | 2 |
| Tone Controls (Bass/Treble) | ±14 dB @50 Hz / ±14 dB @10 kHz |
| Input Sensitivity | Mic: 5.5 mV / Line: 1.3 V / RCA: 130 mV |
| Frequency Response | 20 Hz–20 kHz (4/8Ω); 80 Hz–15 kHz (70V/100V) |
| Total Harmonic Distortion | <0.5% |
| Signal-to-Noise Ratio | >76 dB |
| Input Impedance | Mic: 400 Ω / Line: 20 kΩ / RCA: 50 kΩ |
| Phantom Power | 27 VDC |
| Crosstalk | -70 dB |
| AC Line Voltage | 100–240V, 50/60 Hz |
| Minimum Load Impedance | 4Ω / 40Ω / 80Ω |
| Operating Temperature/Humidity | 0–35°C @ 95% R.H. |
| Storage Temperature | -20–85°C |
| Dimensions (W x D x H) | 17.0 x 16.3 x 3.5 in (432 x 415 x 88 mm) |
| Net Weight | 13.3 kg |
| Shipping Weight | 15.7 kg |
| Origin of Country | China |
