JBL VTX V25-II Full Size 3-Way High-Directivity Line Array With Fixed Angle ASM Suspension

JBL VTX V25-II Full-Size 3-Way Line Array System

The JBL VTX V25-II Full-Size 3-Way Line Array System is engineered for high-performance professional audio applications, combining advanced acoustic technologies with powerful transducers to deliver consistent, transparent, and linear sound across large venues. Designed as a full-size 3-way high-directivity element, the VTX V25-II incorporates a 4th generation high-frequency waveguide, optimizing long-throw performance, wavefront control, and providing improved power matching with Crown IT4x3500HD amplification.

The transducer complement includes two 15-inch Differential Drive® woofers mounted in die-cast aluminum baffles, four 8-inch Differential Drive midrange drivers firing through the patented RBI (Radiation Boundary Integrator®), and three D2 Dual-Diaphragm Dual-Voice-Coil Compression Drivers loaded onto the newly designed waveguide. This combination ensures accurate low, mid, and high-frequency reproduction, delivering exceptional sound clarity and dynamics for both touring and fixed installations.

The system integrates JBL’s patented S.A.F.E.™ Suspension System with fixed-angle tension suspension hardware, allowing quick setup, safe rigging, and precise array configuration. V5 Processing with Crown I-Tech HD or VRACK provides flexible system integration and control, complemented by JBL HiQnet Performance Manager™ software for detailed configuration and monitoring. The enclosure combines cast aluminum front baffles with Finnish birch plywood finished in black DuraFlex™, ensuring durability, reduced weight, and efficient heat transfer.

The VTX V25-II is ideal for large-scale live events, theaters, and houses of worship where long-throw, high-output, and precise coverage are critical. Its robust rigging options, flexible array geometry, and professional-grade construction make it a reliable solution for high-demand sound reinforcement applications.

Features of VTX V25-II

• New 4th generation HF waveguide technology

• D2 Dual-Diaphragm Dual Voice Coil Compression Driver

• Patented RBI Radiation Boundary Integrator®

• Aluminum front baffles for reduced height and improved heat transfer

• Patented JBL S.A.F.E.™ Suspension System

• V5 Processing with Crown I-Tech HD or VRACK

• JBL HiQnet Performance Manager™ system control

• Available fixed-angle or compression suspension hardware

• High-output, linear, and transparent sound

• 90° horizontal coverage for consistent dispersion

Specifications of VTX V25-II
