JBL VRX932LAP/230 | 12″ Two-Way Powered Line Array Speaker System

JBL VRX932LAP 12 in. Powered Two-Way Line Array Loudspeaker System

The JBL VRX932LAP 12 in. Powered Two-Way Line Array Loudspeaker System is a compact, lightweight speaker engineered for small to mid-size venues requiring high-quality line-array performance without the need for long-throw coverage. Each enclosure weighs 24 kg (52 lb) and can be arrayed with up to five units, providing precise, coherent audio with fast setup.

This powered system features a Differential Drive® 12-inch woofer and three high-frequency drivers mounted on a constant curvature waveguide, ensuring consistent vertical coverage of 15° per cabinet. Multiple cabinets can be combined into arrays to achieve a total vertical coverage of up to 75°, with evenly spaced drivers maintaining coherent sound throughout the array. The integrated JBL DrivePack® DPC-2 amplifier module provides ample power, while onboard DSP and EQ optimize system performance for any venue configuration.

Built-in rigging hardware, M10 suspension points, a dual-angle pole-mount socket, and compatibility with optional array frames allow versatile installation options, whether flown or pole-mounted. The Array Configuration Selector (ACS) enables amplitude shading for tailored coverage and high-frequency distribution. The enclosure is constructed from 25/15 mm, 11-ply birch plywood with a durable black DuraFlex™ finish. The front is protected by a powder-coated, 16-gauge perforated steel grille backed with acoustically transparent foam, ensuring robust durability without affecting sound quality.

Ideal for live performance, DJ systems, and permanent installations, the JBL VRX932LAP combines compact size, high-output sound, and flexible deployment features, delivering professional-quality line-array performance in a portable, easy-to-set-up package.

Features of VRX932LAP

• 12-inch Differential Drive® woofer

• Three HF drivers on a constant curvature waveguide

• Powered with JBL DrivePack® DPC-2 amplifier module

• Integrated DSP for system optimization and EQ

• Vertical coverage 15° per cabinet; arrays up to 75° vertical

• Dual-angle pole-mount socket for flexible positioning

• M10 suspension points for flying arrays

• Array Configuration Selector (ACS) for amplitude shading

• Optional VRX-AF line array frame and 10 mm forged eyebolts

• Durable 11-ply birch plywood enclosure with black DuraFlex™ finish

• Powder-coated 16-gauge steel grille with acoustically transparent foam

Specifications of VRX932LAP
