RCF HDL 26-A 2,000W 2-Way Line Array Speaker – White

RCF HDL 26-A active two-way line array module

The RCF HDL 26-A active two-way line array module is a compact and efficient touring system designed for small to mid-sized indoor and outdoor applications. Built with advanced acoustic engineering, it incorporates two 6-inch neodymium woofers and a 3-inch titanium compression driver to deliver clear vocal reproduction and balanced frequency response. With a peak output of 133 dB SPL, the system is powered by a 2000W Class-D amplifier, ensuring reliable performance with low distortion and strong low-frequency extension.

The integrated 4PATH waveguide ensures controlled 100° x 10° dispersion, providing consistent audience coverage and accurate high-frequency projection. With a crossover frequency set at 750 Hz, the system achieves smooth transition between drivers, enhancing clarity and intelligibility. The onboard DSP operates at high resolution to manage crossover, protection, and system optimization, while FiRPHASE technology maintains phase coherence and precise sound imaging with minimal latency.

The enclosure is constructed from lightweight composite material, offering durability and ease of handling in touring environments. Its advanced rigging mechanism allows flexible array configurations with precise alignment control. RDNet integration provides full remote monitoring and system management, enabling real-time adjustments across multiple modules. The HDL 26-A combines compact size, intelligent control, and high-performance output, making it a dependable solution for professional audio systems.

Features of HDL 26-A

• 2000W peak Class-D amplifier system
• Bi-amped two-way active configuration
• 133 dB maximum SPL output
• High-resolution DSP processing engine
• RDNet remote control and monitoring
• FiRPHASE phase-aligned filtering technology
• 3-inch titanium compression driver
• Dual 6-inch neodymium low-frequency drivers
• 750 Hz crossover frequency optimization
• 4PATH waveguide for precise dispersion
• 100° x 10° consistent coverage pattern
• Hybrid bandpass low-frequency design
• Lightweight and durable composite enclosure
• Flexible array rigging system
• High efficiency with reduced distortion
• Built-in thermal and RMS protection
• Professional XLR and Ethercon connections
• Compact form factor for easy deployment

Specifications of HDL 26-A
