Bose AMM112 Multipurpose Loudspeaker

Bose AMM112 multipurpose loudspeaker

The Bose AMM112 multipurpose loudspeaker is the larger full-range model in the AMM series, featuring a passive, coaxial 2-way design that pairs a 3 inch compression driver with a 12 inch low-frequency transducer for high output up to 131dB peak. Compared to the AMM108, the AMM112 needs a cabinet roughly 50 percent larger and weighs nearly double at 22 kg, reflecting its step up in output and low-frequency extension.

Power handling increases substantially over the AMM108, reaching 300W long-term and 2800W peak at a sensitivity of 96dB, giving the AMM112 a maximum continuous SPL of 121dB (131dB peak). The loudspeaker can be switched to run passively through its internal crossover, or bi-amped via an external crossover for greater control in demanding sound reinforcement applications.

As with the rest of the AMM range, the AMM112 shares Beamwidth Matching Waveguide technology and voicing consistency with Bose AM array modules and AMU utility loudspeakers, letting system designers mix and match across product lines for FOH, foldback or fill roles at larger venues than the AMM108 alone can comfortably cover.

Finished in an understated polyurethane coating over a Baltic pine cabinet without prominent Bose branding, the AMM112 suits professional touring, house of worship, and corporate event applications that need a step up in output and bass extension while retaining the coherent, feedback-resistant character of a coaxial point-source design.

Features

• Passive, coaxial 2-way multipurpose loudspeaker
• 12 inch woofer, 3 inch compression driver
• 131 dB peak output
• 300W long-term / 2800W peak power handling
• Sensitivity 96dB, max SPL 121dB continuous
• Switchable passive or bi-amp operation
• Beamwidth Matching Waveguide for consistent coverage
• Consistent voicing with AM array and AMU loudspeakers
• 22 kg cabinet, roughly 50% larger than AMM108
• Baltic pine cabinet, polyurethane coating
