Eversolo DAC Z10 Fully Balanced Preamplifier with Remote

Eversolo DAC-Z10 Precision Reference Digital-to-Analog Converter

Eversolo DAC-Z10 is a flagship precision DAC designed to deliver uncompromised digital-to-analog conversion with extreme clarity, accuracy, and dynamic range. Built for audiophiles and professional listening environments, it focuses on preserving the purest possible audio signal through advanced isolation, clocking, and conversion technologies.

At the core of the DAC-Z10 is Eversolo’s Fully Isolated Architecture (FIA), which completely separates digital and analog circuits to eliminate interference and preserve signal integrity. The system employs three independent ultra-low-noise linear power supplies dedicated to the left channel, right channel, and system processing, ensuring stable and isolated power delivery for each section.

The DAC uses dual AK4191 + AK4499 conversion modules in a fully balanced dual-mono configuration, allowing independent processing of left and right channels. This architecture, combined with AKM Velvet Sound technology, delivers high dynamic range, low distortion, and rich tonal accuracy.

A precision R2R resistor-based volume control system ensures analog-level accuracy without digital degradation, preserving micro-details even at low listening levels. The fully balanced preamplifier stage supports both XLR and RCA outputs, offering high headroom and ultra-low noise performance.

Clock precision is managed through OCXO temperature-controlled oscillators, PLL synchronization, and FPGA-based clock reconstruction. This ensures stable timing and reduces jitter for accurate high-resolution playback.

The DAC-Z10 supports multiple high-resolution formats, including DSD512 and PCM up to 768 kHz/32-bit, with multi-core USB processing for lossless data transmission. Extensive input options include IIS, AES/EBU, coaxial, optical, USB, ARC HDMI, and Bluetooth connectivity.

Additional engineering features include isolated signal paths, grounding noise reduction, external clock support, and advanced FPGA signal shaping for optimal digital processing before conversion.

The chassis is constructed from aviation-grade aluminum for durability and shielding against electromagnetic interference. A large 8.8-inch IPS display provides intuitive control, system visualization, and real-time signal monitoring. Mobile app control and touchscreen interaction further enhance usability.

Designed for both technical precision and user experience, the DAC-Z10 combines reference-level audio performance with modern connectivity and control flexibility.

Features of DAC-Z10

• Fully isolated digital and analog architecture (FIA)
• Dual-mono AK4191 + AK4499 DAC configuration
• Independent left/right linear power supplies
• Ultra-low noise power design
• R2R analog volume control system
• Fully balanced preamplifier stage (XLR/RCA support)
• OCXO temperature-controlled clock system
• FPGA-based clock reconstruction
• Supports DSD512 and PCM 768 kHz/32-bit
• Multi-core USB audio processing engine
• Extensive input options including IIS, AES/EBU, coaxial, optical, USB, ARC, Bluetooth
• Ultra-low distortion and wide dynamic range performance
• External 10 MHz / 25 MHz clock support
• Grounding noise isolation system
• Aviation-grade aluminum chassis construction
• 8.8-inch IPS touchscreen display
• Mobile app and touchscreen control system
• Adjustable digital filter modes
• High-resolution signal path visualization

Specifications of DAC-Z10
