RCF MH 61EN Two-Way Voice Alarm Horn Speaker
RCF MH 61EN is a two-way plastic horn loudspeaker intended for alarm messages and music reproduction. It provides the specified format for a carefully planned professional audio installation and the associated system connection arrangement.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 1,942.50 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
RCF MH 61EN Two-Way Voice Alarm Horn Speaker
The RCF MH 61EN is a two-way plastic horn loudspeaker intended for alarm messages and music reproduction. The woofer and dome tweeter provide an extended driver arrangement, with transformer taps, ceramic terminals and a protected enclosure for the specified installation.
The specified frequency response is 100 Hz – 20000 Hz. Rated power handling is 60 W. The nominal impedance is 8 ohm. Maximum sound pressure level at one metre is 115 dB. These characteristics define how the component fits into the supported audio arrangement and provide the starting point for selecting the associated equipment and operating settings.
The physical specification lists height 332 mm, width 418 mm, depth 391 mm, weight 7.35 kg. The enclosure material is ABS. The specified finish is Grey – RAL 7035. The productÂ’s physical format should be considered alongside the installation position, the surrounding equipment and the space required to reach its connection points.
Speaker placement should be planned around the listening area and the type of coverage required. Mounting position, distance from listeners and the surrounding room layout all affect the complete installation. The loudspeakerÂ’s specified connection method and load should be matched to the selected amplification system before the final layout is established.
For a distributed sound installation, consider the speaker position and cable route together. The chosen operating settings should remain consistent with the amplifier and the connected speaker line. Keep the relevant connection points accessible during assembly, and use the model-specific mounting instructions to establish the final orientation and physical attachment arrangement.
Features of MH 61EN
- 6.5″ woofer with 1″ dome tweeter.
- Power selectable (100 V): 60 W – 30 W – 15 W – 7.5 W.
- 99 dB sensitivity.
- Colour Grey – RAL 7035
- Plastic body.
- In/out ceramic terminal block.
- Thermal fuse protection.
- Protection grade IP66.
Specifications of MH 61EN
| Product Type | Two-Way Voice Alarm Horn Speaker |
| Brand | RCF |
| Model | MH 61EN |
| Manufacturer Part Number | 13100042 |
| Frequency Response (-10dB) | 100 Hz – 20000 Hz |
| Max SPL @ 1m | 115 dB |
| Max SPL @ 4m | 103 dB |
| Horizontal coverage angle | 70° |
| Vertical coverage angle | 90° |
| System Sensitivity | 99 dB |
| System Sensitivity 1W @ 4m | 87 dB |
| Nominal Impedance | 8 ohm |
| Power Handling | 60 W |
| Peak Power Handling | 240 W PEAK |
| Protections | Thermal fuse |
| Dome Tweeter | 1 x 1.0” |
| Woofer | 1 x 6.5” |
| Input connectors | Ceramic screw terminals |
| Output connectors | Ceramic screw terminals |
| Constant Voltage Transformer | 100 V |
| Power selection 1 | 60 W – 167 ohm |
| Power selection 2 | 30 W – 333 ohm |
| Power selection 3 | 15 W – 667 ohm |
| Power selection 4 | 7.5 W – 1333 ohm |
| IP protection grade | IP 66 |
| EN54-24 certified | Yes |
| Cabinet/Case Material | ABS |
| Hardware | Steel bracket |
| Color | Grey – RAL 7035 |
| Height | 332 mm / 13.07 inches |
| Width | 418 mm / 16.46 inches |
| Depth | 391 mm / 15.39 inches |
| Weight | 7.35 kg / 16.2 lbs |
