Ecler eCMP8 Music Projector Speaker

Ecler eCMP8 music projector loudspeaker

The Ecler eCMP8 is a music projector built in a compact, high-efficiency format for demanding outdoor and semi-outdoor commercial applications. It combines an 8 inch low frequency transducer with a 1.4 inch coaxial high frequency transducer in a single waterproof and sun-screening enclosure, delivering a nominal power handling of 150W RMS at 8 ohm.

Rated IP56, the eCMP8 is water resistant and treated against prolonged sun exposure, making it well suited to terraces, poolside areas, gardens, shopping walkways and other spaces where a loudspeaker faces the elements. It supports both direct low impedance connection and a 70/100V distributed line transformer, with 100V power taps of 37.5W, 75W and 150W, halved for a 70V line, giving installers flexibility when integrating it into a wider distributed audio system.

Coverage is defined by a wide 100 degree by 100 degree dispersion pattern, giving broad and even sound projection across open outdoor areas without requiring an excessive number of units. Frequency response reaches from 80Hz to 18kHz (-3dB), with a sensitivity of 96dB (1W/1m) and a maximum sound pressure level of 117dB at 1 metre, supporting clear background music and paging in busy environments.

The eCMP8 is built for commercial, hospitality, education, corporate, sports and house of worship applications where a discreet, weather-resistant loudspeaker is required. Its compact dimensions and mounting bracket allow straightforward installation on walls, poles or overhangs, giving system designers a reliable outdoor solution that pairs consistent sound quality with long-term durability.

Features

• Compact high-efficiency music projector
• 8 inch LF driver and 1.4 inch HF coaxial driver
• IP56 rated for outdoor and water-exposed use
• 150W RMS power handling at 8 ohm
• 70/100V line transformer with 37.5/75/150W taps
• Wide 100 degree x 100 degree dispersion
• Frequency response 80Hz-18kHz (-3dB)
• Sensitivity 96dB (1W/1m)
• Maximum SPL 117dB at 1 metre
• Sun-screening treated enclosure material
• Mounting bracket included
