JBL NVMA1120-34-UK 5 input x 60/120/240W output Mixer/Amplifiers
The JBL NVMA1120-34-UK Mixer-Amplifier delivers reliable commercial audio performance with 120W output, low and high-impedance support, independent tone controls, multiple input options, and compact 1U rack-mountable design.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 3,432.77 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
JBL NVMA1120-34-UK Mixer-Amplifier
The JBL NVMA1120-34-UK Mixer-Amplifier is a versatile audio solution designed for professional commercial environments. Offering 120W per channel, it supports both low-impedance speaker loads (4Ω/8Ω) and high-impedance distributed audio systems (70V/100V), making it ideal for offices, retail spaces, conference rooms, and other commercial applications. Its 1U fanless design ensures quiet operation and easy integration into standard audio racks.
This model features five inputs and one output, with independent bass and treble controls for precise tonal adjustment on each channel. The unit includes paging chime functionality, priority muting, and compatibility with JBL CSR-V in-wall volume controllers, providing flexible and convenient remote control of audio levels. Connectivity options include balanced mic/line inputs and unbalanced RCA inputs, supporting a wide range of audio sources.
Engineered for reliable performance, the NVMA1120-34-UK delivers low distortion (<0.5% THD), wide frequency response (20 Hz–20 kHz for low-impedance output, 80 Hz–15 kHz for high-impedance output), and high signal-to-noise ratio (>76 dB). The unit operates efficiently across international AC voltages (100–240V, 50/60 Hz) and is built for commercial durability. The JBL NVMA1120-34-UK Mixer-Amplifier combines professional audio quality, operational flexibility, and easy installation, making it a practical solution for modern commercial sound systems.
Features of NVMA1120-34-UK
5 inputs and 1 output with 120W power
Supports low-impedance (4Ω/8Ω) and high-impedance (70V/100V) outputs
Independent bass and treble adjustment per channel
Paging chime and priority muting
Compatible with JBL CSR-V wall controllers
Balanced mic/line inputs and unbalanced RCA inputs
Rack mounting hardware included
Wide frequency response and low distortion
High signal-to-noise ratio
Supports 100–240V AC operation
Fanless, compact 1U rack design
Durable commercial-grade construction
Specifications of NVMA1120-34-UK
| Max Output Power | 120 W @ 4/8Ω (1 kHz, ≤0.5% THD) |
| Insertion Loss (70V/100V) | 1 dB max |
| Number of Inputs | 5 |
| Number of Outputs | 1 |
| Tone Controls (Bass/Treble) | ±14 dB @50 Hz / ±14 dB @10 kHz |
| Input Sensitivity | Mic: 5.5 mV / Line: 1.3 V / RCA: 130 mV |
| Frequency Response | 20 Hz–20 kHz (4/8Ω); 80 Hz–15 kHz (70V/100V) |
| Total Harmonic Distortion | <0.5% |
| Signal-to-Noise Ratio | >76 dB |
| Input Impedance | Mic: 400 Ω / Line: 20 kΩ / RCA: 50 kΩ |
| Phantom Power | 27 VDC |
| Crosstalk | -70 dB |
| AC Line Voltage | 100–240V, 50/60 Hz |
| Minimum Load Impedance | 4Ω / 40Ω / 80Ω |
| Operating Temperature/Humidity | 0–35°C @ 95% R.H. |
| Storage Temperature | -20–85°C |
| Dimensions (W x D x H) | 17.0 x 16.3 x 3.5 in (432 x 415 x 88 mm) |
| Net Weight | 9.2 kg |
| Shipping Weight | 11.6 kg |
| Origin of Country | China |
