JBL NVMA160-34-EU 5 input x 60/120/240W output Mixer/Amplifiers
The JBL NVMA160-34-EU Mixer-Amplifier delivers reliable 60W commercial audio with low and high-impedance support, independent tone controls, versatile input options, and a compact 1U fanless rack-mount design.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 2,689.21 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
JBL NVMA160-34-EU Mixer-Amplifier
The JBL NVMA160-34-EU Mixer-Amplifier is a cost-effective, professional audio solution designed for commercial and industrial environments. Offering 60W per channel, it supports low-impedance speaker loads (4Ω/8Ω) and high-impedance distributed audio systems (70V/100V), providing flexible deployment options for offices, retail spaces, educational facilities, and other commercial installations. Its compact 1U fanless design ensures quiet operation and easy integration into standard audio racks.
The NVMA160-34-EU features five inputs and a single output, with independent bass and treble controls for precise tonal adjustment on each channel. Additional features include paging chime functionality and priority muting, as well as compatibility with JBL CSR-V in-wall volume controllers for convenient remote operation. Connectivity options include balanced mic/line inputs and unbalanced RCA inputs, accommodating a variety of audio sources.
Engineered for dependable performance, this model delivers low distortion (<0.5% THD), wide frequency response (20 Hz–20 kHz for low-impedance output, 80 Hz–15 kHz for high-impedance output), and high signal-to-noise ratio (>76 dB). The amplifier operates efficiently across AC voltages from 100–240V at 50/60 Hz and is designed to withstand standard commercial temperature and humidity conditions. The JBL NVMA160-34-EU Mixer-Amplifier combines professional-grade audio quality, operational flexibility, and energy-efficient performance, making it ideal for modern commercial sound applications.
Features of NVMA160-34-EU
5 inputs and 1 output with 60W power
Supports low-impedance (4Ω/8Ω) and high-impedance (70V/100V) outputs
Independent bass and treble adjustment per channel
Paging chime and priority muting
Compatible with JBL CSR-V wall controllers
Balanced mic/line inputs and unbalanced RCA inputs
Rack mounting hardware included
Wide frequency response and low distortion
High signal-to-noise ratio
Supports 100–240V AC operation
Fanless, compact 1U rack design
Durable commercial-grade construction
Specifications of NVMA160-34-EU
| Max Output Power | 60 W @ 4/8Ω (1 kHz, ≤0.5% THD) |
| Insertion Loss (70V/100V) | 1 dB max |
| Number of Inputs | 5 |
| Number of Outputs | 1 |
| Tone Controls (Bass/Treble) | ±14 dB @50 Hz / ±14 dB @10 kHz |
| Input Sensitivity | Mic: 5.5 mV / Line: 1.3 V / RCA: 130 mV |
| Frequency Response | 20 Hz–20 kHz (4/8Ω); 80 Hz–15 kHz (70V/100V) |
| Total Harmonic Distortion | <0.5% |
| Signal-to-Noise Ratio | >76 dB |
| Input Impedance | Mic: 400 Ω / Line: 20 kΩ / RCA: 50 kΩ |
| Phantom Power | 27 VDC |
| Crosstalk | -70 dB |
| AC Line Voltage | 100–240V, 50/60 Hz |
| Minimum Load Impedance | 4Ω / 80Ω / 160Ω |
| Operating Temperature/Humidity | 0–35°C @ 95% R.H. |
| Storage Temperature | -20–85°C |
| Dimensions (W x D x H) | 17.0 x 16.3 x 3.5 in (432 x 415 x 88 mm) |
| Net Weight | 8.8 kg |
| Shipping Weight | 11.2 kg |
| Origin of Country | China |
