JBL NVMA1240-34-UK 5 input x 60/120/240W output Mixer/Amplifiers
The JBL NVMA1240-34-UK Mixer-Amplifier provides powerful 240W commercial audio, supporting low and high-impedance outputs, independent tone controls, versatile input options, and a compact fanless 1U rack-mount design.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 4,176.33 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
JBL NVMA1240-34-UK Mixer-Amplifier
The JBL NVMA1240-34-UK Mixer-Amplifier is a professional-grade audio solution designed for commercial and industrial applications. Delivering 240W per channel, it supports low-impedance speaker loads (4Ω/8Ω) as well as high-impedance distributed systems (70V/100V), making it ideal for offices, retail spaces, conference rooms, and other commercial environments. Its fanless, compact 1U chassis ensures quiet operation and easy integration into standard audio racks.
Equipped with five inputs and one output, the NVMA1240-34-UK features independent bass and treble controls on each channel, allowing precise tonal adjustment for different acoustic settings. Additional functionality includes paging chime, priority muting, and compatibility with JBL CSR-V in-wall volume controllers for convenient remote operation. Connectivity includes balanced mic/line inputs and unbalanced RCA inputs, enabling flexible integration with various audio sources.
Engineered for reliability and performance, this amplifier delivers low distortion (<0.5% THD), wide frequency response (20 Hz–20 kHz for low-impedance output, 80 Hz–15 kHz for high-impedance output), and a high signal-to-noise ratio (>76 dB). It operates efficiently across AC voltages from 100–240V at 50/60 Hz, ensuring consistent performance in different regions. The JBL NVMA1240-34-UK Mixer-Amplifier combines professional audio quality, energy-efficient operation, and intuitive control, making it a dependable choice for modern commercial sound installations.
Features of NVMA1240-34-UK
5 inputs and 1 output with 240W power
Supports low-impedance (4Ω/8Ω) and high-impedance (70V/100V) outputs
Independent bass and treble adjustment per channel
Paging chime and priority muting
Compatible with JBL CSR-V wall controllers
Balanced mic/line inputs and unbalanced RCA inputs
Rack mounting hardware included
Wide frequency response and low distortion
High signal-to-noise ratio
Supports 100–240V AC operation
Fanless, compact 1U rack design
Durable commercial-grade construction
Specifications of NVMA1240-34-UK
| Max Output Power | 240 W @ 4/8Ω (1 kHz, ≤0.5% THD) |
| Insertion Loss (70V/100V) | 1 dB max |
| Number of Inputs | 5 |
| Number of Outputs | 1 |
| Tone Controls (Bass/Treble) | ±14 dB @50 Hz / ±14 dB @10 kHz |
| Input Sensitivity | Mic: 5.5 mV / Line: 1.3 V / RCA: 130 mV |
| Frequency Response | 20 Hz–20 kHz (4/8Ω); 80 Hz–15 kHz (70V/100V) |
| Total Harmonic Distortion | <0.5% |
| Signal-to-Noise Ratio | >76 dB |
| Input Impedance | Mic: 400 Ω / Line: 20 kΩ / RCA: 50 kΩ |
| Phantom Power | 27 VDC |
| Crosstalk | -70 dB |
| AC Line Voltage | 100–240V, 50/60 Hz |
| Minimum Load Impedance | 4Ω / 20Ω / 40Ω |
| Operating Temperature/Humidity | 0–35°C @ 95% R.H. |
| Storage Temperature | -20–85°C |
| Dimensions (W x D x H) | 17.0 x 16.3 x 3.5 in (432 x 415 x 88 mm) |
| Net Weight | 11.6 kg |
| Shipping Weight | 14.0 kg |
| Origin of Country | China |
