JBL PD566-WH 15-inch Horn-Loaded Full-Range Loudspeaker – White
15-inch Precision Directivity horn-loaded loudspeaker with 60° x 60° coverage, designed for high-output applications. Ideal for music or speech systems, with rotatable waveguide and optional pairing with subwoofers for extended full-range performance.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 23,637.10 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
JBL PD566 15-inch Horn-Loaded Full-Range Loudspeaker
The JBL PD566 is a professional 15-inch horn-loaded loudspeaker engineered to deliver high output with precise pattern control. It is perfect for standalone music or speech systems with frequency extension to 80 Hz, or it can be integrated with subwoofers to achieve extended full-range sound.
The speaker features a 380 mm (15 in) horn-loaded low-frequency driver and a 38 mm (1.5 in) exit compression driver (JBL 2432H) for clear high-frequency reproduction. Large PT™ Progressive Transition waveguides provide 60° x 60° coverage, low distortion at high SPL levels, and smooth frequency response. The waveguide is rotatable for horizontal or vertical cabinet orientation.
A sophisticated, steep-slope passive crossover network with switchable bi-amp/passive modes ensures system flexibility and optimal performance. The trapezoidal enclosure is constructed from 18 mm exterior-grade 11-ply Finnish birch plywood, finished with durable DuraFlex™ coating.
This model is suitable for sports facilities, performance venues, auditoriums, and worship spaces that require reliable, high-fidelity sound reinforcement.
Features of PD566
15-inch horn-loaded low-frequency driver
1.5-inch exit compression driver (JBL 2432H)
PT™ Progressive Transition waveguides for 60° x 60° coverage
Rotatable waveguide for horizontal or vertical orientation
Bi-amp/passive switchable crossover network
Low distortion at high SPL
Trapezoidal birch plywood enclosure with DuraFlex™ finish
Black finish standard; White (-WH) optional
Weather-resistant for WRC/WRX configurations
M10 threaded suspension points for secure mounting
Acoustically transparent, powder-coated steel grille
Specifications of PD566
| Product Type | Horn-Loaded Full-Range Loudspeaker |
| LF Driver | 15″ horn-loaded woofer (2031H) |
| HF Driver | 1.5″ exit compression driver (JBL 2432H), 75 mm (3 in) voice coil |
| Nominal Output Power | 450 W (LF), 75 W (HF) |
| System Power Rating | Passive mode: 500 W 2 hrs, 300 W 100 hrs (IEC) |
| Frequency Response | 70 Hz – 20 kHz |
| Frequency Response (±3 dB) | 90 Hz – 17 kHz |
| Nominal Impedance | 8 Ohms |
| Maximum SPL | LF: 133 dB cont (139 peak) HF: 133 dB cont (139 peak) |
| System Sensitivity | 104 dB SPL (1W @ 1m) |
| Passive Crossover | 1.3 kHz |
| Coverage Pattern | 60° H x 60° V |
| Enclosure Material | 18 mm exterior grade 11-ply Finnish birch plywood |
| Enclosure Design | Trapezoidal |
| Finish | Black DuraFlex™ (White optional) |
| Waveguide | PT-H66HF-1, 300 x 300 mm |
| Dimensions (H x W x D) | 782 x 783 x 670 mm (30.8 x 30.8 x 26.4 in) |
| Net Weight | 69 kg (152 lb) |
| Origin of Country | Mexico |
