RCF MQ 80P W Two-Way Sound Projector – White

RCF MQ 80P W Two-Way Sound Projector – White

The RCF MQ 80P W is a white two-way horn-loaded sound projector for indoor and outdoor installations. The enclosure combines a woofer and high-frequency driver, with a dedicated aiming bracket and selectable connection settings for distributed sound systems.

The specified frequency response is 100 Hz – 20000 Hz. Rated power handling is 60 W. The nominal impedance is 8 ohm. Maximum sound pressure level at one metre is 114 dB. These characteristics define how the component fits into the supported audio arrangement and provide the starting point for selecting the associated equipment and operating settings.

The physical specification lists height 223 mm, width 191 mm, depth 236 mm, weight 3.65 kg. The enclosure material is Plastic. The specified finish is White – RAL 9016. The product’s physical format should be considered alongside the installation position, the surrounding equipment and the space required to reach its connection points.

Speaker placement should be planned around the listening area and the type of coverage required. Mounting position, distance from listeners and the surrounding room layout all affect the complete installation. The loudspeaker’s specified connection method and load should be matched to the selected amplification system before the final layout is established.

For a distributed sound installation, consider the speaker position and cable route together. The chosen operating settings should remain consistent with the amplifier and the connected speaker line. Keep the relevant connection points accessible during assembly, and use the model-specific mounting instructions to establish the final orientation and physical attachment arrangement. The final arrangement should follow the documented product configuration and remain matched to the intended system components.

Features of MQ 80P W

• 5″ woofer with 1″ compression driver
• Power selectable (100 V): 30 W – 20 W – 10 W – 5 W
• 94 dB sensitivity
• Colour White – RAL 9016
• Plastic body, steel grille
• Protection grade IP 55

Specifications of MQ 80P W
