Ecler ePHS30Ti Horn Cabinet Industrial Loudspeaker

Ecler ePHS30Ti horn loudspeaker

The Ecler ePHS30Ti is a 30W horn loudspeaker designed for high-performance paging and background music reproduction in 70/100V line public address systems. Engineered to deliver clear, focused sound with strong speech intelligibility, it is ideal for large outdoor and industrial environments requiring long-throw audio coverage.

Manufactured from reinforced ABS, the horn enclosure provides excellent durability and resistance to harsh environmental conditions. With an IP66 weather protection rating, the ePHS30Ti is fully protected against dust ingress and powerful water jets, making it suitable for permanent outdoor installations in demanding climates.

The unit operates in high or low impedance modes via a rear-panel power selector, arriving pre-configured for 70/100V 30W line operation. A frequency response of 400Hz to 10kHz (-3dB) and a sensitivity of 108dB (1W/1m) give the ePHS30Ti strong projection and intelligibility over long distances.

Selectable power tappings for both 70V and 100V systems ensure flexible system integration and efficient distributed audio design. Finished in light grey/white (RAL9013), the ePHS30Ti is well suited to industrial sites, transport hubs, sports stadiums and other large outdoor venues requiring dependable long-throw paging.

Features of ePHS30Ti

• 30W horn loudspeaker for 70/100V applications
• 6.5-inch driver, long-throw horn design
• IP66 rated for demanding outdoor use
• Reinforced ABS construction
• High or low impedance operation via rear selector
• Frequency response 400Hz-10kHz (-3dB)
• 108dB sensitivity (1W/1m)
• Suited to industrial and large outdoor venues

Specifications of ePHS30Ti
