Description
JBL AC26 dual 6.5-inch 2-way loudspeaker
The JBL AC26 is an ultra-compact, high-output 2-way loudspeaker designed for professional fixed-installation applications. Manufactured in Mexico, it is part of JBL’s AE Compact family within the AE Series, delivering precise audio performance, consistent coverage, and flexible installation in a space-efficient enclosure. It is ideal for designers and performers who need clear, reliable sound in small to medium-sized venues.
The AC26 features two 165 mm (6.5-inch) low-frequency transducers paired with a 25 mm (1-inch) exit compression driver, providing detailed high-frequency response and accurate midrange tones. Its PT™ Progressive Transition waveguide provides a 90° x 90° coverage pattern, ensuring even sound dispersion and controlled off-axis response. Passive crossover circuitry and FIR-style tuning optimize frequency and phase response, enhancing coverage consistency and overall sound quality.
The enclosure is built from 12 mm and 15 mm exterior-grade multi-ply hardwood plywood with a white textured finish, offering durability and a clean, professional appearance. Dual Neutrik NL4 connectors and screw terminals provide secure and flexible connection options. Multiple M8 and M6 suspension points allow mounting with optional U-brackets, OmniMount® brackets, or stand mount accessories for walls, ceilings, or stands.
The AC26 is suitable for performing arts facilities, theatrical sound design, auditoriums, houses of worship, live and dance clubs, sports venues, and themed entertainment spaces, offering compact, reliable, and high-quality sound reinforcement.
Features of AC26
Dual 6.5-inch low-frequency drivers for accurate midrange and bass
25 mm exit compression driver for clear highs
90° x 90° PT™ waveguide for consistent coverage
Ultra-compact 2-way design for space-efficient installation
360 W program power handling for reliable output
Dual Neutrik NL4 connectors plus screw terminals
Multiple suspension points for flexible mounting
White finish for professional aesthetic integration
Specifications of AC26
| Frequency Range (-10 dB) | 55 Hz – 20 kHz |
| Frequency Response (±3 dB) | 70 Hz – 18 kHz |
| System Power Rating (AES) | 350 W |
| Power Rating (IEC) | 180 W Continuous / 360 W Program / 720 W Peak |
| Nominal Impedance | 8 ohms |
| Coverage Pattern | 90° × 90° |
| Maximum SPL (1m) | 117 dB |
| System Sensitivity (1W @ 1m) | 92 dB SPL |
| LF Driver | 2 × JBL 226J, 165 mm (6.5-inch) SFG™ drivers |
| LF Driver Voice Coil | 50 mm (2-inch), edge-wound |
| HF Driver | 1 × 2414H, 25 mm exit compression driver, 25 mm voice coil |
| Enclosure Material | 12 mm & 15 mm multi-ply hardwood plywood |
| Suspension Attachment | 6 × M8 points; 4 × M6 rear for OmniMount® or MultiMount® |
| Dimensions (H × W × D) | 539.8 × 199.4 × 226.1 mm |
| Net Weight | 11.0 kg |
| Environmental Rating | Mil-Std 810, IPx3 (IEC 529) |
| Finish | White |
| Country of Origin | Mexico |
