JBL CBT 100LA-1 Constant Beamwidth Technology Line Array Column Loudspeaker – Black

JBL CBT 100LA-1 black

The JBL CBT 100LA-1 black line array column loudspeaker utilizes Constant Beamwidth Technology™ to provide consistent vertical coverage while minimizing narrow beaming and out-of-coverage lobing. Featuring sixteen 50 mm (2 in) full-range drivers, this speaker delivers uniform sound distribution, ideal for venues requiring controlled pattern performance and high intelligibility.

The vertical coverage is adjustable between 15° for long-throw applications and 40° for medium-throw, with a fixed 150° horizontal coverage. Switchable voicing enables either a flat response for music or a mid-range presence peak for speech. A built-in 70V/100V multi-tap transformer and direct 8-ohm input offer versatile integration into distributed speaker systems.

The CBT 100LA-1 black is built with a fiberglass-reinforced ABS cabinet and painted aluminum grille for durability and professional aesthetics. The included swivel (pan)/tilt wall bracket allows continuous horizontal and vertical adjustment, while 18 M6 threaded insert points enable secure suspension or mounting with third-party brackets. Designed for both indoor and outdoor use, it is IP55-rated when used with the optional MTC-PC2 terminal panel cover, offering protection against moisture, UV, and salt spray.

Ideal for lecture halls, auditoriums, transit spaces, and professional audio installations, the CBT 100LA-1 black combines high power, precise pattern control, and flexible mounting for demanding sound reinforcement needs.

Features of CBT 100LA-1

• Sixteen 50 mm (2 in) full-range drivers for consistent coverage

• Constant Beamwidth Technology™ for uniform vertical pattern control

• Switchable vertical coverage: 15° long-throw, 40° medium-throw

• Horizontal coverage: 150° (±20°)

• Switchable voicing: flat music or mid-range speech mode

• 325 W continuous (1300 W peak, 2 hrs) power handling

• Built-in 70V/100V transformer and 8-ohm direct input

• Dynamic SonicGuard™ overload protection

• Fiberglass-reinforced ABS cabinet with painted aluminum grille

• IP55-rated with optional MTC-PC2 cover for outdoor use

• Swivel (pan)/tilt wall bracket included

• 18 M6 threaded insert points for suspension or third-party brackets

• Optional accessories: flush-mount bracket, stand-mount bracket, terminal panel cover

• Origin of Country: China

Specifications of CBT 100LA-1
