JBL F35/95 Dual 15-inch 3-Way Loudspeaker
The JBL F35/95 Dual 15-inch 3-Way Loudspeaker is a high-performance full-range system engineered for applications requiring controlled 90° x 50° coverage and exceptional output capability. Designed in a lightweight trapezoidal enclosure, the F35/95 integrates advanced JBL transducer technologies with precision waveguide control and amplifier-optimized processing for professional touring and installed sound environments.
The low-frequency section incorporates dual 2265H 15-inch Differential Drive transducers, each utilizing dual 3-inch voice coils and neodymium magnet structures. This configuration enhances thermal efficiency, reduces distortion, and provides strong continuous power handling. The mid-frequency range is reproduced by a 2169H 8-inch Dual Voice Coil Neodymium Differential Drive transducer, ensuring articulate vocal and instrument clarity. High frequencies are managed by the D2430H D2 dual diaphragm, dual voice coil compression driver, delivering extended high-frequency response and high dynamic output.
With integrated V5 processing for Crown I-Tech HD series amplifiers, the system achieves optimized acoustic performance and reliable system alignment. Dual NL8 input connectors support multi-channel signal routing for tri-amplified configurations.
Constructed from 18 mm, 11-ply Finnish birch plywood with a durable black DuraFlex finish, the enclosure is reinforced for demanding applications. Multiple integrated M10 mounting points enable flexible suspension configurations, making the JBL F35/95 suitable for flown arrays and fixed installations requiring precise 90° x 50° coverage control.
Features of F35/95
High output 3-way loudspeaker system
Dual 15-inch Differential Drive LF transducers
8-inch Differential Drive MF transducer
D2430H D2 dual diaphragm compression driver
90° x 50° coverage pattern
V5 processing compatibility
Designed for Crown I-Tech HD amplifiers
Lightweight trapezoidal enclosure
Multiple integrated M10 suspension points
18 mm Finnish birch plywood construction
Durable DuraFlex finish
Dual NL8 input connectivity
Specifications of F35/95
| System Type | High Performance Dual 15-inch 3-Way Loudspeaker with 90° x 50° coverage |
| Frequency Range (-10 dB) | 39 Hz – 18 kHz |
| Coverage Pattern (-6 dB) | 90° Horizontal x 50° Vertical |
| System Input Power Rating | LF: 2 x 800 W Continuous; MF: 270 W Continuous; HF: 100 W Continuous |
| Maximum Peak Output | 143 dB |
| System Impedance | LF: 2 x 8 ohms; MF: 8 ohms; HF: 8 ohms |
| LF Driver | 2 x 2265H, 254 mm (15 in), dual 76 mm voice coils, Neodymium Differential Drive |
| MF Driver | 1 x 2169H, 203 mm (8 in), dual 76 mm voice coil |
| HF Driver | 1 x D2430H D2 dual diaphragm, dual 76 mm voice coil |
| Enclosure | 18 mm, 11-ply Finnish birch plywood; black DuraFlex finish |
| Grille | 14-gauge powder-coated hex-perforated steel with acoustic cloth backing |
| Input Connectors | 2 x Neutrik Speakon NL8 (LF1: 1±, LF2: 2±, MF: 3±, HF: 4±) |
| Dimensions (H x W x D) | 1051.5 mm x 568.9 mm x 528.3 mm |
| Net Weight | 52.6 kg |
| Suspension / Mounting | Integrated M10 mounting points |
| Origin of Country | Mexico |
