RCF F-16XR 16-Channel Mixer with Multi-FX Recoding
The RCF F 16XR analog mixer delivers professional multi-channel mixing with USB recording, onboard DSP effects, multiple compressors, flexible routing, and high-quality balanced outputs for live and studio applications.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 3,140.55 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
RCF F 16XR professional analog mixer
The RCF F 16XR professional analog mixer is designed to provide advanced audio mixing capabilities for live sound, studio recording, and professional installations. As part of the RCF F Series, it combines robust analog architecture with modern digital processing tools, delivering high-quality sound performance with flexible control and routing options.
With 16 input channels, including 10 microphone preamps, 4 mono line inputs, and 4 stereo line inputs, the F 16XR supports a wide range of professional audio sources. The mixer features a fully balanced main output path with +28 dBu output capability, ensuring clean, powerful, and distortion-free signal transmission. Its 60 mm faders provide precise level control for each channel, enabling smooth and accurate mixing.
The integrated PRO DSP FX engine offers 16 professional-grade effects, including reverbs, delays, chorus, flanger, and echo, allowing users to enhance and shape their sound without external processors. Additionally, the built-in USB audio interface enables stereo recording and playback, making it suitable for DAW-based workflows and live recording applications.
Advanced routing options include two stereo output busses and four auxiliary sends (with flexible pre/post configurations), offering extensive signal distribution capabilities. Six single-control compressors on channels 1 to 6 provide dynamic control for vocals and instruments, improving clarity and consistency. Designed with a durable metal chassis and an internal universal power supply, the RCF F 16XR ensures reliability and long-term performance in demanding environments.
Features of F 16XR
- 16-channel analog mixer architecture
- 10 high-quality microphone preamps
- 4 mono line inputs
- 4 stereo line inputs
- Integrated PRO DSP FX with 16 presets
- Stereo USB recording and playback
- Six single-control compressors
- Balanced main output up to +28 dBu
- Dual stereo output busses
- 4 auxiliary sends with flexible routing
- 60 mm precision channel faders
- 3-band EQ with semi-parametric mid section
- Phantom power support (+48V)
- HI-Z instrument input support
- High dynamic range performance
- Internal universal power supply
- Durable metal chassis construction
- Designed and engineered in Italy
Specifications of F 16XR
| Frequency Response | 20 Hz – 20 kHz |
| THD+N | <0.02% A-Weighted |
| Dynamic Range | >85 dB |
| Total Channels | 16 |
| Mic Inputs | 10 |
| Mic Gain Range | 0 dB to -50 dB |
| Input Noise Level | -124 dBu A-Weighted |
| Mic Input Impedance | 14 kohm |
| Low Cut Filter | 80 Hz |
| Phantom Power | +48V |
| Mono Line Inputs | 8 |
| HI-Z Input | 1 (1 Mohm) |
| Stereo Line Inputs | 4 |
| Line Input Impedance | 21 kohm (mono), 14 kohm (stereo) |
| Input Connectors | XLR, Jack, RCA |
| Main Output | 1 (Stereo XLR + TRS) |
| Control Room Output | Yes |
| FX Send | 1 |
| AUX Sends | 3 |
| AUX Outputs | 4 |
| Group Outputs | 4 |
| Headphone Output | 1 |
| Output Connectors | XLR, Jack |
| Main Output Level | +28 dBu |
| Aux Output Level | +28 dBu |
| Group Output Level | +28 dBu |
| Headphone Output Level | 10 dBm |
| Headphone Impedance | 150 ohm |
| Compressors | 6 single-control compressors (Ch 1–6) |
| EQ Type | 1 Semi-parametric / 2 Shelving |
| EQ High | ±15 dB @ 10 kHz |
| EQ Mid | ±15 dB (100 Hz – 8 kHz selectable) |
| EQ Low | ±15 dB @ 100 Hz |
| Internal Effects | 16 presets |
| USB Audio Interface | Yes |
| USB Type | Type B |
| Playback Channels | 2 |
| Recording Channels | 2 |
| Supported Sample Rates | 44.1 kHz, 48 kHz |
| Footswitch | Yes |
| Power Supply | Internal |
| Voltage Range | 100 – 240 V |
| Power Consumption | 30 W |
| Compliance | CE compliant |
| Cabinet Material | Metal |
| Color | Black |
| Height | 107 mm |
| Width | 479 mm |
| Depth | 406 mm |
| Weight | 6.4 kg |
| Package Weight | 7.4 kg |
