RCF F 24XR professional analog mixer
The RCF F 24XR professional analog mixer is the flagship model of the F Series, designed to deliver advanced audio mixing performance for large-scale live sound, studio recording, and professional installations. Built with a robust analog architecture and integrated digital processing, it provides exceptional sound quality, flexible routing, and precise control for complex audio environments.
Featuring 24 input channels, including 18 microphone preamps, 16 mono line inputs, and 4 stereo line inputs, the F 24XR supports extensive connectivity for microphones, instruments, and external audio devices. The fully balanced main output path ensures clean, high-headroom signal transmission with professional-grade clarity. High-quality 60 mm faders provide smooth and accurate control across all channels.
The integrated PRO DSP FX engine offers 16 professional presets, including reverbs, delays, chorus, flanger, and echo effects, allowing advanced sound shaping without external processors. The built-in USB audio interface enables stereo recording and playback, making it ideal for DAW integration and live recording workflows. Six single-control compressors on channels 1 to 6 provide dynamic control, ensuring consistent vocal and instrument performance.
Advanced routing options include two stereo output busses and four auxiliary sends with flexible pre/post configurations, enabling comprehensive system design and monitoring. The mono channels feature a 3-band EQ with selectable mid frequency, while stereo channels include a dedicated 3-band EQ for precise tonal shaping. Designed with a durable metal chassis, internal universal power supply, and engineered in Italy, the RCF F 24XR delivers reliability, power, and professional-grade performance for demanding audio applications.
Features of F 24XR
- 24-channel analog mixer architecture
- 18 high-quality microphone preamps
- 16 mono line inputs
- 4 stereo line inputs
- Integrated PRO DSP FX with 16 presets
- Stereo USB recording and playback
- Six single-control compressors
- Balanced main output (Stereo XLR + TRS)
- Dual stereo output busses
- 4 auxiliary sends with flexible routing
- 60 mm precision channel faders
- 3-band EQ with selectable mid frequency
- 3-band EQ on stereo channels
- Phantom power support (+48V)
- HI-Z instrument input support
- High dynamic range performance
- Internal universal power supply
- Durable metal chassis construction
- Designed and engineered in Italy
Specifications of F 24XR
| Frequency Response | 20 Hz – 20 kHz |
| THD+N | <0.02% A-Weighted |
| Dynamic Range | >85 dB |
| Total Channels | 24 |
| Mic Inputs | 18 |
| Mic Gain Range | 0 dB to -50 dB |
| Input Noise Level | -124 dBu A-Weighted |
| Mic Input Impedance | 14 kohm |
| Low Cut Filter | 80 Hz |
| Phantom Power | +48V |
| Mono Line Inputs | 16 |
| HI-Z Input | 1 (1 Mohm) |
| Stereo Line Inputs | 4 |
| Line Input Impedance | 21 kohm (mono), 14 kohm (stereo) |
| Input Connectors | XLR, Jack, RCA |
| Main Output | 1 (Stereo XLR + TRS) |
| Control Room Output | Yes |
| FX Send | 1 |
| AUX Sends | 3 |
| AUX Outputs | 4 |
| Group Outputs | 2 |
| Headphone Output | 1 |
| Output Connectors | XLR, Jack |
| Main Output Level | +28 dBu |
| Aux Output Level | +28 dBu |
| Group Output Level | +28 dBu |
| Headphone Output Level | 10 dBm |
| Headphone Impedance | 150 ohm |
| Compressors | 6 single-control compressors (Ch 1–6) |
| EQ Type | 1 Semi-parametric / 2 Shelving |
| EQ High | ±15 dB @ 10 kHz |
| EQ Mid | ±15 dB (100 Hz – 8 kHz selectable) |
| EQ Low | ±15 dB @ 100 Hz |
| Internal Effects | 16 presets |
| USB Audio Interface | Yes |
| USB Type | Type B |
| Playback Channels | 2 |
| Recording Channels | 2 |
| Supported Sample Rates | 44.1 kHz, 48 kHz |
| Footswitch | Yes |
| Power Supply | Internal |
| Voltage Range | 100 – 240 V |
| Power Consumption | 70 W |
| Compliance | CE compliant |
| Cabinet Material | Metal |
| Color | Black |
| Height | 107 mm |
| Width | 720 mm |
| Depth | 406 mm |
| Weight | 9.5 kg |
| Package Weight | 12.5 kg |
