RCF F-10XR 10-Channel Mixer with Multi-FX and Stereo USB Interface

RCF F 10XR compact analog mixer

The RCF F 10XR compact analog mixer is designed to provide high-quality sound performance and flexible mixing capabilities for musicians, live performers, and audio professionals. As part of the advanced F Series, it combines RCF’s analog expertise with modern digital enhancements, offering reliable and precise audio control in a compact format.

Equipped with 10 input channels, including 4 microphone inputs and multiple stereo line inputs, the F 10XR supports a wide range of audio sources. The mixer maintains a fully balanced main output signal path, ensuring clean and noise-free audio from input to output. Mono channels are equipped with 3-band equalization, while stereo channels feature 2-band EQ, allowing detailed sound shaping for different input types.

The integrated PRO DSP FX engine includes 16 professional effects such as reverb, delay, chorus, flanger, and echo. Additionally, the built-in USB audio interface allows stereo recording and playback, enabling seamless integration with computer-based digital audio workstations. Two single-control compressors on channels 1 and 2 provide dynamic control, enhancing vocal and instrument clarity.

Designed with a sturdy metal chassis, the F 10XR ensures durability and reliability in both studio and live environments. Its compact design, combined with an external universal power supply, makes it suitable for portable and fixed setups. Designed and engineered in Italy, the RCF F 10XR delivers professional-grade performance with flexible functionality.

Features of F 10XR

• 10-channel analog mixer configuration
• 4 microphone input channels
• Stereo recording and playback via USB
• Integrated PRO DSP FX with 16 presets
• Balanced main output signal path
• Two single-control compressors
• 3-band EQ on mono channels
• 2-band EQ on stereo channels
• Auxiliary FX send (post-fader)
• Phantom power support (+48V)
• Multi-format input connectivity
• High dynamic range performance
• Compact and portable design
• Durable metal chassis construction
• External universal power supply
• Designed and engineered in Italy

Specifications of F 10XR
