Bose ControlSpace EX-8ML Mic/GPIO Dante Endpoint
The Bose ControlSpace EX-8ML is an 8-channel microphone and GPIO Dante endpoint that brings additional microphone inputs and control connections into a ControlSpace system over a single networked cable run.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 7,668.15 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
Description of EX-8ML.
Bose ControlSpace EX-8ML 8-channel mic/GPIO Dante endpoint
The Bose Professional ControlSpace EX-8ML is the highest-capacity microphone endpoint in the ControlSpace EX accessory family, offering eight channels of microphone or line-level input in a single Dante-networked unit. It is designed for rooms with a larger number of local microphone connections, such as boardrooms, lecture halls, or divisible meeting spaces.
Each of the eight input channels is converted to Dante audio and carried back to the connected ControlSpace EX processor over the network, removing the need to run individual analog microphone cables across the room. General-purpose input and output connections are also included, allowing the EX-8ML to interface with buttons, indicator lights, or other control hardware as part of the room’s overall control scheme.
As with the smaller EX-4ML and EX-UH endpoints, the EX-8ML draws both power and network connectivity from a single Cat-5/6 cable using PoE, and multiple endpoints can be daisy-chained from a shared power source. This keeps wiring consistent and predictable across a project that may use several endpoint types in different rooms.
Configuration takes place in ControlSpace Designer software, where autodiscovery and auto-routing simplify bringing the EX-8ML online alongside other Dante devices. The unit’s low-profile aluminium housing is designed for discreet placement under tables, in equipment closets, or within furniture, depending on where microphone connections are required.
Features of EX-8ML
- 8-channel mic/line Dante endpoint with GPIO
- Highest-capacity microphone endpoint in the EX family
- Suited to boardrooms and larger conferencing spaces
- General-purpose I/O for external control hardware
- Single Cat-5/6 cable with PoE for power and network
- Daisy-chainable across multiple endpoints
- Autodiscovery and auto-routing via ControlSpace Designer
- Low-profile aluminium enclosure
- Compatible with EX-1280C, EX-12AEC, and EX-440C
- Consistent wiring alongside EX-4ML and EX-UH endpoints
Specifications of EX-8ML
| Device Type | 8-channel mic/GPIO Dante endpoint |
| Audio Channels | 8 mic/line inputs |
| Control I/O | General-purpose input/output |
| Connectivity | Gigabit network port with PoE |
| Digital Conversion | 48 kHz, 24-bit |
| DC Power In | +12 V DC, 1 A |
| Dimensions (W x L x H) | 216 x 206 x 27 mm |
| Enclosure | Low-profile aluminium |
| Configuration Software | ControlSpace Designer |
| Compatible Processors | EX-1280C, EX-12AEC, EX-440C, EX-1280 |
