JBL AM5215/64-WH 15-inch 2-Way Loudspeaker with 60° x 40° Rotatable Horn – White
The JBL AM5215/64 15-inch 2-Way Loudspeaker with 60° x 40° Rotatable Horn in white delivers precise full-range sound, medium power output, lightweight design, and flexible orientation for professional audio applications.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 13,705.83 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
JBL AM5215/64 15-inch 2-Way Loudspeaker
JBL AM5215/64 15-inch 2-Way Loudspeaker with 60° x 40° Horn in white is a medium-power, full-range loudspeaker system designed for professional sound reinforcement. It incorporates a JBL Differential Drive® 265H-1 380 mm (15 in) low-frequency driver with dual voice coil and dual magnetic gap, along with a 2408H-1 38 mm (1.5 in) exit high-frequency compression driver. The PT™ Progressive Transition waveguide ensures accurate coverage, low distortion, and consistent sound across a variety of listening environments.
The rotatable waveguide allows use in both vertical and horizontal orientations, making it suitable for auditoriums, performing arts facilities, worship venues, live clubs, dance clubs, sports arenas, and themed entertainment locations. High-slope passive networks reduce band overlap, and the controlled off-axis response enhances arrayability for complex audio setups. The system supports Bi-Amp and passive modes, with FIR tuning to optimize frequency response, phase alignment, and coverage consistency.
The trapezoidal enclosure is built from 16 mm exterior-grade birch plywood with 15° side angles and includes 15 suspension points for versatile rigging. A powder-coated steel grille with acoustically transparent foam protects the drivers without affecting clarity. Available in white, the JBL AM5215/64 provides reliable, professional-grade performance with clear, balanced sound suitable for medium-power applications.
Features of AM5215/64
60° x 40° rotatable coverage pattern
265H-1 Differential Drive® low-frequency driver
2408H-1 high-frequency compression driver
Large PT™ Progressive Transition waveguide for precise pattern control
Rotatable waveguide for vertical or horizontal orientation
Bi-Amp/Passive switchable operation
FIR tuning for optimized frequency, phase response, and coverage consistency
Available in White, Black, and WRC/WRX weather-resistant finishes
Specifications of AM5215/64
| Frequency Range (-10 dB) | 35 Hz – 20 kHz |
| Frequency Response (±3 dB) | 41 Hz – 18 kHz |
| Coverage Pattern | 60° x 40° |
| Directivity Factor (Q) | 14.5 |
| Directivity Index (DI) | 11.6 dB |
| Crossover Modes | Bi-amp/Passive switchable |
| Passive Crossover Frequency | 2 kHz |
| Transducer Power Rating (AES) | LF: 500 W (2000 W peak), HF: 40 W (160 W peak) |
| System Power Rating | Passive mode: 350 W (1400 W peak), Bi-amp mode: LF: 125 dB-SPL cont avg, HF: 131 dB-SPL cont avg |
| System Sensitivity (1W @ 1m) | 98 dB SPL |
| LF Driver | 1 x JBL 265H-1 380 mm (15 in) dual voice coil |
| HF Driver | JBL 2408H-1, 38 mm exit compression driver |
| Nominal Impedance | 8 ohms |
| Waveguide | PT-H66HF-1 |
| Enclosure | Trapezoidal, 16 mm birch plywood, 15° side angles |
| Suspension Attachment | 15 points, M10 threaded hardware |
| Finish | White DuraFlex™ finish |
| Grille | Powder-coated 14 gauge perforated steel with black foam backing |
| Input Connector | NL4 Neutrik Speakon® and CE-compliant barrier strip |
| Environmental | Mil-Std 810; IP-x3 per IEC529 |
| Dimensions (H x W x D) | 783 x 422 x 504 mm (30.8 x 16.6 x 19.85 in) |
| Net Weight | 25.0 kg (55 lb) |
| Optional Accessories | M10 x 35 mm forged eyebolts, U-Bracket MTU-1 |
| Origin of Country | Mexico |
