JBL AM7215/66-WH 15-inch 2-Way Loudspeaker with 60° x 60° Rotatable Horn – White
The JBL AM7215/60 15-inch 2-Way Loudspeaker in white delivers high-power, full-range sound with 60° x 60° coverage, JBL Differential Drive technology, and a rotatable waveguide for professional audio applications.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
AED 20,502.92 Inc VAT
-
Pick up from the Woodmart Store
To pick up today
Free
-
Delivery Service
Our courier will deliver to the specified address
1-3 Days
Charges as per location
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year/ or per brand policy
-
Free 7 Days returns policy
Payment Methods:
Description
JBL AM7215/60 15-inch 2-Way Loudspeaker
JBL AM7215/60 15-inch 2-Way Loudspeaker with 60° x 60° Rotatable Horn in white finish is a high-power, lightweight, full-range loudspeaker system engineered for professional sound reinforcement. It incorporates the JBL Differential Drive® 2265H low-frequency driver, 380 mm (15 in) with 75 mm (3 in) dual voice coil and dual magnetic gap, delivering powerful and accurate bass output.
The high-frequency section includes the JBL 2432H compression driver with a 38 mm (1.5 in) exit and 75 mm (3 in) voice coil, ensuring clear and detailed treble. The large-format Progressive Transition™ waveguide guarantees uniform 60° x 60° coverage, precise pattern control, and minimal distortion.
The rotatable waveguide allows flexible installation in vertical or horizontal orientation. High-slope passive networks minimize band overlap for smooth frequency response and improved arrayability. The AM7215/60 is ideal for performing arts centers, auditoriums, worship venues, live and dance clubs, sports arenas, and themed entertainment environments.
The trapezoidal enclosure is made from 16 mm exterior-grade 11-ply Finnish birch plywood with 15° side angles, and features multiple M10 suspension points for secure mounting. The professional white finish provides durability and aesthetic versatility. Origin of country mexico.
Features of AM7215/60
60° x 60° coverage
2265H Differential Drive® low-frequency driver
2432H high-frequency compression driver
Large Progressive Transition™ waveguide for precise pattern control and low distortion
Rotatable waveguide for vertical or horizontal orientation
Bi-Amp/Passive switchable operation
FIR-tuned for optimized frequency and phase response, consistent coverage, and sound quality
White finish for seamless professional installation
Specifications of AM7215/60
| Frequency Range (-10 dB) | 34 Hz – 20 kHz |
| Frequency Response (±3 dB) | 40 Hz – 18 kHz |
| Coverage Pattern | 60° x 60° |
| System Type | 15-inch 2-Way, High Power, Full-Range |
| Crossover Modes | Bi-amp/Passive switchable |
| Passive Crossover Frequency | 1.8 kHz |
| Transducer Power Rating (AES) | LF: 1000 W (4000 W peak), HF: 100 W (400 W peak) |
| System Power Rating | Passive mode: 600 W (2400 W peak), 100 hrs |
| Maximum SPL (1 m) | Bi-amp mode: LF 128 dB cont avg (134 dB peak), HF 135 dB cont avg (141 dB peak); Passive mode: 124 dB cont avg (130 dB peak) |
| System Sensitivity (1W @ 1m) | Passive mode: 96 dB SPL |
| LF Driver | JBL 2265H 380 mm (15 in) Differential Drive® driver, 75 mm dual voice coil |
| HF Driver | JBL 2432H, 38 mm (1.5 in) exit compression driver, 75 mm voice coil |
| Nominal Impedance | 8 ohms |
| Nominal LF Driver Impedance | 8 ohms |
| Nominal HF Driver Impedance | 8 ohms |
| Enclosure | Trapezoidal, 16 mm exterior-grade 11-ply Finnish birch plywood |
| Suspension Attachment | 15 points, M10 threaded hardware |
| Environmental | Mil-Std 810; IP-x3 per IEC529 |
| Dimensions (H x W x D) | 781 x 420 x 503 mm |
| Net Weight | 27.2 kg |
| Optional Accessories | U-Bracket MTU-1 |
| Origin of Country | Mexico |
